Wavelength Range 325 - 1100nm, Split Beam Spectrophotometer T60V

Wavelength Range 325 - 1100nm, Split Beam Spectrophotometer T60V

small.img.alt small.img.alt

Large Image :  Wavelength Range 325 - 1100nm, Split Beam Spectrophotometer T60V Get Best Price

Product Details:
Brand Name: PG instruments
Certification: CE
Model Number: T60V Visible Spectrophotometer
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Contact for a Quote
Packaging Details: Carton package, 550x500x350mm, 16kg
Delivery Time: Contact for confirmation
Payment Terms: T/T, L/C
Supply Ability: 2500 units per year
Detailed Product Description
High Light:

UV Visible Spectroscopy


Heavy Metal Analyzer



Wavelength range 325 - 1100nm, Split Beam Visible Spectrophotometer T60V


T60V (Visible) is a split beam system operating within a wavelength range of 190-1100nm. The instrument has a switched model power supply accepting voltages in the range of 95-240V AC and supplied with either universal path length 5 cell changer or fixed path length 8 cell changer as standard. T60V delivers the functionality and accuracy of an advanced instrument at an affordable price.

High quality optical components ensure reliable analytical data with low stray light achieved using very low noise electronic circuits.

Deuterium and tungsten light source deliver superior stability across the full wavelength range. Both types of lamp have self timers and are inexpensive and easy to replace when required.

The monochromator is completely sealed and the optical surfaces can be easily cleaned to maintain optimum reflectivity over the lifetime of the instrument.

A maintenance free high resolution direct stepper drive positions the grating precisely, which ensures reproducible wavelength scanning at different scan speed, thus negating any wavelength peak shift.

The Spectrophotometer shell is made from an environmentally friendly non corrosive material and a simple retaining mechanism on the base allows easy access for air filter changes and routine maintenance.

Features & Functions

High performance fixed 2nm spectral bandwidth
Holographic blazed grating 1200lines/mm
Local control software for photometric fixed wavelength measurement
Easily upgraded to include quantitative analysis, multi wavelength spectrum & kinetics
Built in cell holder storage
Robust modular design with a small footprint
Can be used with UV Win Software (optional). CFR21 Part 11 Software Options are available


Education in universities and colleges
Environmental monitoring & control
Food & Beverage production and quality control
Agricultural monitoring
Geology & Metallurgy
Gas & oil



Optical system

Split beam ratio

Scan speed


Wavelength range


Wavelength accuracy


Wavelength reproducibility


Spectral bandwidth


Photometric mode

Transmittance, Absorbance, Energy

Photometric range


Photometric accuracy

0.002A (0-0.5A), 0.004A (0.5-1A), 0.3%T (0-100%T)

Photometric reproducibility

00.001A(0-0.5A), 0.002A(0.5-1A), 0.15%T(0-100%T)

Photometric noise

0.001A(500nm) 30min warm-up

Baseline flatness


Baseline stability

0.001A/h (500nm, 0Abs), 2hr warm-up

Stray light

≤1.0%T(340nm NaNO2)

Standard functionality

Photometric & Quantitative Measurement


Silicon photo diode

Light source

Tungsten Halogen


Digital LCD display


Mini printer

PC interface


Software support

Local and UV Win

Power supply

Switch mode 95-250VAC 50-60Hz







Standard Accessories


2x10mm glass cells

Black block

Mains power lead

2A fuse

Dust cover

Operators manual

Calibration and system documentation



Optional Accessories & Consumables


Sipper pump

Solid sample holder

Constant temperature holder

5 position cell holder

8 position cell holder

Single position cell/test tube holder

Micro printer

Cells package

Deuterium lamp

Tungsten lamp
