T60U Split Beam Spectrophotometer with Tungsten Halogen and Deuterium Arc Lamps
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | metal analysis spectrometer,Heavy Metal Analyzer |
||
|---|---|---|---|
Split Beam Spectrophotometer T60U with Tungsten Halogen and Deuterium Arc lamps
Applications:
Education in universities and colleges
Environmental monitoring & control
Food & Beverage production and quality control
Agricultural monitoring
Geology & Metallurgy
Gas & oil
Specifications:
|
Optical system |
Split beam ratio |
|
Scan speed |
Selectable |
|
Wavelength range |
190-1100nm |
|
Wavelength accuracy |
+1nm |
|
Wavelength reproducibility |
≤0.2nm |
|
Spectral bandwidth |
2nm |
|
Photometric mode |
Transmittance, Absorbance, Energy |
|
Photometric range |
-0.3-3.0Abs |
|
Photometric accuracy |
0.002A (0-0.5A), 0.004A (0.5-1A), 0.3%T (0-100%T) |
|
Photometric reproducibility |
00.001A(0-0.5A), 0.002A(0.5-1A), 0.15%T(0-100%T) |
|
Photometric noise |
0.001A(500nm) 30min warm-up |
|
Baseline flatness |
0.002A(200-1000nm) |
|
Baseline stability |
0.001A/h (500nm, 0Abs), 2hr warm-up |
|
Stray light |
≤0.05%T(220nm NaI, 340nm NaNO2) |
|
Standard functionality |
Photometric Measurement (Quantitative, Multi-wavelength, Spectrum and Kinetic measurements with program cards) |
|
Detector |
Silicon photo diode |
|
Light source |
Tungsten Halogen and Deuterium arc lamps |
|
Display |
Digital LCD display |
|
Printer |
Mini printer |
|
PC interface |
RS232 |
|
Software support |
Local and UV Win |
|
Power supply |
Switch mode 95-250VAC 50-60Hz |
|
Weight |
11kg |
|
Dimension |
476x362x225mm |
Standard Accessories
Quantitative program card
2x10mm quartz cells
Black block
Mains power lead
2A fuse
Dust cover
Operators manual
Calibration and system documentation
Optional Accessories & Consumables
Multi wavelength program card
Scanning and Kinetics program card
DNA/Protein program card
Palm Oil program card
Sipper pump
Solid sample holder
Constant temperature holder
5 position cell holder
8 position cell holder
Single position cell/test tube holder
Micro printer
Cells package
Deuterium lamp
Tungsten lamp
T60U (UV-Visible) is a split beam system operating within a wavelength range of 190-1100nm. The instrument has a switched model power supply accepting voltages in the range of 95-240V AC and supplied with either universal path length 5 cell changer or fixed path length 8 cell changer as standard. T60U delivers the functionality and accuracy of an advanced instrument at an affordable price.
High quality optical components ensure reliable analytical data with low stray light achieved using very low noise electronic circuits.
Deuterium and tungsten light source deliver superior stability across the full wavelength range. Both types of lamp have self timers and are inexpensive and easy to replace when required.
The monochromator is completely sealed and the optical surfaces can be easily cleaned to maintain optimum reflectivity over the lifetime of the instrument.
A maintenance free high resolution direct stepper drive positions the grating precisely, which ensures reproducible wavelength scanning at different scan speed, thus negating any wavelength peak shift.
The Spectrophotometer shell is made from an environmentally friendly non corrosive material and a simple retaining mechanism on the base allows easy access for air filter changes and routine maintenance.
Features & Functions
High performance fixed 2nm spectral bandwidth
Low stray light 0.05%T
Wavelength accuracy +1nm
Holographic blazed grating 1200lines/mm
Local control software for photometric fixed wavelength measurement
Easily upgraded to include quantitative analysis, multi wavelength spectrum & kinetics
Built in cell holder storage
Robust modular design with a small footprint
Can be used with UV Win Software (optional). CFR21 Part 11 Software Options are available
