Compatible Visible Portable Spectrometer C30 Flat-Field Holographic Concave Grating
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | Flame Atomic Absorption Spectrometer,double beam spectrophotometers |
||
|---|---|---|---|
Compatible Visible Portable Spectrometer C30, Flat-field Holographic Concave Grating
The C30 portable spectrometer is a compact portable instrument based on advanced CCD detection technology.
Whilst being highly compact, the instrument boasts all the features of a conventional bench-top
spectrophotometer including Spectrum Scanning, Photometric, Quantitative and Kinetic methods.
Due to its portable design, it is also ideal for field monitoring and on-site operations for water and
food analysis.
Features & Functions
- Packed in a rugged carry case
- A Windows CE embedded operating system
- 4.3 inch 480*272 colour touch screen TFT interface
- 2GB memory for extensive data storage
- Pre-programmed test methods for water and food analysis (optional)
- Use rectangular cell, round test tubes and fiber probe
- Outstanding flat-field holographic concave grating
- Multiple interface including USB, RS232, Ethernet, GPS and SIM card
- GPS positioning and GPRS mobile wireless data transmission
- Lithium battery continuously work for 6 hours after fully charged
- l A wide range of sample preparation accessories
Applications:
Environmental
Food & Beverage
Agricultural
Clinical
Specifications:
|
Light source |
Convergent tungsten lamp, 500hr of service life |
|
|
Measurement modes |
Spectrum scan, quantitative measurement, kinetics measurement, photometric measurement |
|
|
Monochromator |
Flat-field holographic concave grating |
|
|
Detector |
CCD 1L x 511 2048 pixel |
|
|
Sampling accessories |
Insert optic fiber probe, 10mm and 20mm pathlength tips; ectangular cuvette holder; cylindrical test tube holder |
|
|
Power supply |
Built-in battery, continuously work for 6 hours after being charged Vehicle power supply adapter (optional) Battery charger (90-240V) |
|
|
Printer |
Micro printer (optional), support USB printer (PLC language) |
|
|
Operating system |
Windows embedded CE 6.0 with 2GB memory and timing function |
|
|
Input/display |
480 x 272 colour touch operation or mouse operation |
|
|
Specifications |
Wavelength range |
380-800nm |
|
Spectral bandwidth |
4.0nm+0.8nm |
|
|
Wavelength error of indication |
+1.0nm |
|
|
Wavelength reproducibility |
≤0.1nm |
|
|
Baseline flatness |
+0.005Abs |
|
|
Noise |
≤0.5% |
|
|
Drift |
≤1.0%/30min |
|
|
Stray light |
≤0.5% |
|
|
Transmittance indication error |
+1.0% |
|
|
Photometric reproducibility |
≤0.3% |
|
|
Dimension |
276.5x169.5x119.5mm |
|
|
Temperature requirements |
Working temperature: 5℃-30℃ Storage temperature: -20℃-55℃ |
|
Standard Accessories
Carry case
Pipettes
Washing bottle
Plain test tube
Centrifuge tubes
Cuvette
Test tubes
Data viewer software
Plastic boxes
Long path length cell holder
Optional Accessories & Consumables
Pulverization module
Measurement module
Ultrasonic module
Heating module
Distillation module
Extraction module
Centrifuge module
Arsenic hydride module
Hydrogen sulfide module
Titration module
Moisture of honey module
Auxiliary module of water analysis
Conductivity module
Optic fiber accessory
Accessory carry case
Reagents for food and water analysis
